New laser spectrometer
T&D-scan for research that
demands high resolution and high spectral
density in UV-VIS-NIR spectral domains - now available with
new pump option! The T&D-scanincludes
a CW ultra-wide-tunable narrow-line laser, high-precision wavelength meter,
an electronic control unit driven through USB interface as well as a
software package. Novel advanced design of the fundamental laser component
implements efficient intra-cavity frequency doubling as well as provides a
state-of-the-art combined ultra-wide-tunable Ti:Sapphire & Dye laser
capable of covering together a
super-broad spectral range between 275 and 1100 nm. Wavelength
selection components as well as the position of the non-linear crystal are
precisely tuned by a closed-loop control
system, which incorporates highly accurate wavelength meter.
Del
Mar Photonics has presented training workshops for customers and potential
customers in the past 3 years.
Our workshops cover laser basics, technical details and provide an
ample time for hands-on training.
Our one week training workshop in San Diego, CA will cover:
* Introduction to continuum wave narrow line-width widely
tunable lasers systems
* Technical and safety issues
* Hand-on training
The workshop is a three-day
seminar from 10am to 4pm. It includes lunch, as well as a training binder. We
have also two days reserved for Q&A sessions, one-on-one system discussions,
social networking and San Diego sightseeing.
The workshop fee is $750
per person*. Workshops are limited (first come,
first served) and require a minimum of 10 attendees, otherwise we reserve the
right to reschedule.
There are no refunds on the registration fee,
however credit to reschedule to a future workshop date is possible.
*We
will credit you $500.00 of your paid workshop fee toward the purchase of your
laser system from Del Mar Photonics, Inc, if you purchase it
within one year of your workshop attendance.
There is also a
discount for multiple attendees from the
same group; second and subsequent registrants will receive 20% off the
registration fee.
Upcoming 2011 summer - fall workshops:
San Diego, CA:
San Diego, CA:
San Diego,
CA:
San Diego,
CA:
San Diego,
CA:
San
Diego,
CA:
Mon - Thurs
June 27 - 30
Mon - Thurs
Aug. 1 - 4
Mon - Thurs
Aug. 15 - 18
Mon - Thurs
Aug. 29 - Sept. 1
Mon - Thurs
Sept. 5 -8
Mon - Thurs
Sept. 12 - 15
E-mail
today to request additional information and to reserve a spot. Additional
workshops will be scheduled if necessary
T&D Scan Laser System installation at Drexel University
Computer-controlled high resolution SPECTROMETER based on broadly tunable CW
laser model TIS-FD-08/A-scan
Del Mar Photonics presents new unique fully computerized powerful laser
spectrometer for research studies demanding fine resolution and high spectral
density of radiation within UV-VIS-NIR spectral domains.
This fully automated high-resolution spectrometer based on Tekhnoscan's CW
narrow-line Ti:Sapphire laser, model TIS-FD-08/A-scan, comes as a perfect
embodiment of modern ideas and technology innovation in the field of smart
laser spectrometers. Novel advanced design of the fundamental laser component
implements efficient intra-cavity frequency doubling as well as provides a
state-of-the-art combined ultra-wide-tunable Ti:Sapphire & Dye laser covering
a super-broad spectral range between 275 and 1100 nm.
The spectrometer includes, as its base, a CW ultra-wide-tunable narrow-line
laser, high-precision wavelength meter, an electronic control unit driven
through USB interface as well as a software package. Positions of wavelength
selection components in the laser as well as the position of the non-linear
crystal are precisely controlled with the help of a closed-loop feed-back
system including a wavelength meter. The spectrometer is fully controllable
through a user-friendly computer interface that offers a variety of modes for
setting and scanning of the radiation wavelength as well as different modes of
data acquisition and recording.
The TIS-FD-08/A-scan features LabWindows™ based software running under
Windows™ XP/Vista. For acquisition of experimental data an 8-channel 14-bit
ADC is used with quantisation frequency of 3 MHz and channel multiplexing
frequency 3 MHz.
The spectrometer is designed for wide-range spectral studies and
characterization of quantum semiconductor structures, meta-materials,
bio-objects as well as for nano-, bio-technological applications, and quality
control.
Laser Spectrometer Specifications
Light source
CW Ti:Sapphire laser 1)
CW Ti:Sapphire laser with intra-cavity frequency doubling 2)
CW Dye laser 3)
CW Dye laser with intra-cavity frequency doubling 4)
Del Mar Photonics, Inc.
4119 Twilight Ridge
San Diego, CA 92130
tel: (858) 876-3133
fax: (858) 630-2376
sales@dmphotonics.com
www.dmphotonics.com
In single- and multi-component nano-scaled materials for efficient energy
harvesting and energy storage, the influences of finite size, shape,
hierarchal complexity and a dynamic surface chemical environment on properties
extend well beyond the constraints posed by traditional materials-specific
property closures of individual material components. In the Mesoscaled
Materials Laboratory (MML) we investigate the synthesis and selected
properties of single- and multi-component inorganic nanostructured and
thin-film materials and devices. We are currently investigating:
functional properties of ferroelectric nanostructures and their surface
chemical environment, with applicability in memory, sensing, in
nanoelectromechanical and photovoltaic energy harvesting, and in other
energy-related areas
development of novel synthetic pathways for multi-component nanostructures for
electronic and photonic devices
electronic transport in low-dimensional semiconductor and metallic materials
and devices, including resonant coupling (and scattering) of electromagnetic
radiation with (and by) nanowires
resonant energy transfer between nanostructures, and its applion in proximal
scanning probes
the physical properties of selected nano-laminate solids and thin films
